Operating instructions for the machine
 Advanced parameters
The parameters of the industrial chiller supplied with the ENERGY machines are preset
(Initial setup). It is not necessary to change these parameters.
1. Hold the key down. Press the key. <SET> (for 5 second(s)).
2. The screen displays the value: 00.
3. Enterthecurrentpassword(thepasswordcon󰄈guredbydefaultis08.)
4. Press the key. <SET>
Theredindicatorlight󰘱ashes(thisindicatesthatthecontrollerisinparametersettingmode.).
Thescreendisplaysthevalue:F0(󰘰rstparameter)
5. Select a parameter.
6. Press the key. <SET>
7. Set the value of the parameter.
8. Press the key. <SET>
9. Select another parameter.
10. Savethemodi󰄈edparameters:Pressthekey.<RST>
The screen returns to temperature adjustment mode.
If no button is pressed within 20 second(s), the controller automatically exits parameter setting mode
withoutsavingthemodi󰄈edparameters.
