Technicalspeci󰘰cations
3. Engraving characteristics
Movement speed (scanning)
LS100 IQ / LS100 EX Maximum: 2540 mm (100.000 in)/s
LS100 ENERGY /
LS100 EX ENERGY
Maximum: 1000 mm (39.370 in)/s
Movement speed (vector) LS100 IQ/EX/ENERGY Maximum: 200 mm (7.874 in)/s
In "fast" mode (hare icon) LS100 EX Maximum: 300 mm (11.811 in)/s
Movement speed (Z) LS100 IQ/EX/ENERGY Maximum: 6 mm (0.236 in)/s
Repeatability LS100 IQ/EX/ENERGY < 0.05 mm (0.002 in)
4. Noise emission of the machine (ISO 11201 standard)
LS100 IQ / LS100 EX
LS100 ENERGY /
LS100 EX ENERGY
30/35/40 W 60/70/80 W 25 W
when awaiting engraving LAeq - dB (A)
≤61 ≤61 ≤52
during nominal engraving (scanning) LAeq - dB (A) ≤70 ≤72 ≤66
5. Environment
Operating temperature 10°C(50°F)-35°C(95°F)
Storage temperature -5°C(23°F)-45°C(113°F)
Humidity level: 5-85%
6. Laser characteristics
LS100 IQ / LS100 EX
LS100 ENERGY /
LS100 EX ENERGY
Classi󰄈cation CDRH: Class 2
Source
CO2 / 30 W - 35 W - 40 W - 55 W - 60
W - 70 W - 80 W
CO2 - 25 W - (water cooling)
Wavelength:
10600nm(10.6μm) 9300nm(9.3μm)
Lens(es) 50.8mm(2.000in)±2%
Aiming diode: wavelength: 645–665nm
