Technicalspeci󰘰cations
7. Electrical characteristics
LS100 IQ / LS100 EX
30 / 35 / 40 W
100–240 V
LS100 IQ / LS100 EX
55 / 60 / 70 / 80 W
120–240 V
LS100 ENERGY
LS100 EX ENERGY
25 W
100–240 V
Nominal voltage 100 - 240 V 120 - 240 V 200 - 240 V
Absorbed current Maximum: 15 A Maximum: 2 A
Frequency 50 - 60 Hz
Absorbed power 1600 W 2000 W 480 W
Protection(s)
Circuit-breaker(s):2x16A
8. Connections and cabling
Port: USB 1.1
Dedicated Inputs/Outputs Sub-D: 15 point connector - Female
Inputs / Outputs: Air extraction
system
DIN: 5 point connector - Female
Cylinder attachment DIN: 8 point connector - Female
Air assist
Pneumatic connection
Internal diameter: 4 mm (0.157 in)
Pressure: 6 Bar (87 PSI) (Maximum)
Air extraction system Internal diameter: 100 mm (3.937 in)
Air󰄉owrate:
- General mode
- With pre-separator
Minimum:
-0,5kPa-(0.07PSI)/200m³/h-(4.36yard³/min).
-6kPa-(0.87PSI)/300m³/h-(6.54yard³/min).
Water chiller (only for ENERGY
machines)
2 brass barb connectors D10
9. Firmware characteristics - driver
Languages(󰄈rmware) FR - EN - DE - IT - ES - NL - BR - HU - TR - PL - JP
File format Gravograph binary encoding
RAM(󰄈rmware) 32 Mo / MB - Storage of multiple jobs
Driver version
Minimum:7.04(󰘰rmware:3.41)
Operating system
(driver)
Windows® 2000 - XP - Vista - 7 - 8 - 10
