Recommendations for installation
 Fillingthetank
1. Fill the tank with demineralised water until the water level reaches the green area (NORMAL) on the
gauge. To avoid any contamination, it is recommended that a biocide be added to the demineralised
water.
1 2
1. Watertankintake
2. Water level gauge
In order to protect the chiller pump, it is strictly prohibited to operate it without demineralised
water in the tank. In order to ensure optimal performance, it is advisable to keep the water
level in the tank within the green area (NORMAL) on the gauge.
Demineralisedwatermustbeusedinthetankinordertopreventdamagetothemetalmaterial.
2. Connect the water hoses between the cooler and the machine.
3. Open the water intake and outlet valves on the cooler.
4. Check that the drain plug is properly tightened.
Checkthatthehosesareproperlyconnected.Makesuretherearenoleaks.
