Appendix: Engraving menu
1. "Parameters" sub-menu
Used to manage the parameters for the current job.
2. "File" sub-menu
Usedtomanagethe󰘰lesimportedintothemachine(Deleting󰘰les...).
3. "Info" sub-menu
Usedtoviewtheinformationrelatedtotheimported󰘰les.
4. "Con󰘰guration"sub-menu
Usedtocon󰘰gurethegeneralmachineparameters.
PARAMETERS
FILE
INFO
CONFIGURATION
PARAMETERS
FILE
INFO
CONFIGURATION
PARAMETERS
FILE
INFO
CONFIGURATION
PARAMETERS
FILE
INFO
CONFIGURATION
L-SOLUTION 900 XP
LANGUAGE XXXXXXX
SERIAL PORT >
DISPLAY UNIT MM
PLC OFF >
LENS
MULTI JOB ON
ENGRAVING ONCE OFF
ALARM END JOB OFF
APF MENU
001 FILENAME1 >
DELETE THIS FILE
DELETE ALL
90%FREEMEMORY
POWER 40
SPEED 10
DPI-X 400
DPI-Y 400
#: 1 0:01:29
001 FILENAME1 >
POWER 40 SPD 10
DPIX 400 DPIY 400
