Operating instructions for the machine
1
Selectionofthenext󰘰le Displayofnext󰘰leinmachinememory,whichbecomescurrent󰘰le
2
Positioning pointer
Activation of a very low power laser beam, providing an indication of the
markingpositionontheplate
3
Air assist Activationofairassistduringmarking
4
Air extractor Activationofairextractionand󰘰ltrationduringmarking
5
Autofocus Automatic focus adjustment (automatic Z Ref.)
6
Start
Startmarking
Start-up engraving
7
Cancel
Exit from menu without applying change to last parameter
Return to reception, during a pause, during end of reception, during end
of engraving
8
Pause Markingsuspended.
9
"Check"key
Accesstothedi󰘯erentmenus
Exit from current menu
Move to next screen
Move to next menu
Validation of the entered data
10
Air assist adjustment
Air󰘱owadjustment
11
Green light - Red light See: "Indicator light(s)"
12
Selection of the previous
󰘰le
Displayofthelast󰘰leinthemachine'smemory,whichbecomesthe
current󰘰le
13
Joystick
Head movement (X, Y, Z)
Movethecursortodi󰘯erentdataentryareas
14
Focus adjustment Manual focus adjustment (manual Z Ref.)
