23
Changing Serial Ports
Click on or tap in the field next to Serial Port.
Type the number of the COM port available for use.
(The system defaults to 1 the first time.)
Click on or tap OK.
Click on or tap Yes to restart WolfSense IAQ LAP
before you start taking readings.
Using Additional External Probes
If you want to use an additional probe, such as an
MIE particulate sensor (see separate manual),
plug it into the PCMIA slot and select
Detect PCMIA Port Probes on the Probe menu.
Because selecting this option slows down
response time, uncheck it when you are not
plugging a probe into the PCMIA slot.
Figure 43 – PROBE SETUP dialog box
Figure 44 – Application Restart Message
Figure 45 – Probe menu
