Introduction
GrayWolf Sensing Solutions provides a fully integrated system for measuring indoor
air quality and ventilation. A laptop computer (Lap PC) running WolfSense™ IAQ
LAP software takes readings of air quality from a probe connected through the serial
port. You may choose to view live readings as they happen, plot readings for a
selected measurement parameter in real time and/or log the readings for future use.
Later, you may use WolfSense™ PC software on the Lap PC to open files of logged
readings for printing, graphing or exporting to a word processor or spreadsheet.
In the DirectSense™ 100 kit, the probe (model IQ-410) has four sensors which
provide five measurements: Temperature (°F/°C), Relative Humidity (%RH), Dew
Point, Carbon Monoxide (CO), and Carbon Dioxide (CO
2
). The Dew Point is derived
from Temperature and Relative Humidity readings.
In the VentCal™ 100 kit, the probe (model CD-201) has two sensors which provide
measurements of Carbon Dioxide, Temperature, and Outdoor Air (OA) ventilation.
VentCal™ software (SOFT-VENT) upgrades the DirectSense™ 100 kit to include all
VentCal™ capabilities.
This manual will get you started. Help files are available in all WolfSense™ software.
Unpacking your GrayWolf Monitor
Figure 1 - Your GrayWolf monitor kit provides everything you need
to get started:
User Manual;
Probe: IQ-410 for DirectSense™ 100 or
CD-201 for VentCal™ 100 (see Figure 2);
ACC-A110 GrayWolf AC adapter (see Figure 2);
ACC-ADY-L9 serial/AC power adapter (see Figure 2);
PCC-05 probe pouch with shoulder strap (see Figure 56);
WolfSense™ software on CD-ROM (contact GrayWolf for
software on 3½” disks);
Fujitsu Lifebook computer (if ordered from GrayWolf) with
Lap-PC-manufacturer-supplied accessories.
NOTE: The VentCal™ software module is unlocked by a modified
serial number found on the CD case and may be installed only if
you have purchased this option from GrayWolf.
