GREENLINE 40 - Page 82

Greenline 40 75
F2 Trim tabs From service bat. via S3 via F28 & F32 12 25
CB
F3 Horn, Search light From service bat. via S3 via F28 & F32 12 25
CB
F4 Radio memory From service bat. via S3 via F28 & F31 12 5
ATO
F5 Cabin, toilet lights From service bat. via S3 via F28 & F32 12 16
CB
F6 Grey water pump From service bat. via S3 via F28 & F32 12 16
CB
F7 Toilet, chain wash pump From service bat. via S3 via F28 & F32 12 16
CB
F8 Diesel heater commands From service bat. via S3 via F28 & F31 12 5
ATO
F9 Diesel heater From service bat. via S3 via F28 & F31 12 16
CB
F10 Cockpit lights From service bat. via S3 via F28 & F31 12 10
CB
F11 Instruments (with
illumination)
From service bat. via S3 via F28 & F32 12 32
CB
F12 Radio, socket 12V From service bat. via S3 via F28 & F32 12 10
CB
F13 Bilge pump From service bat. via S3 via F28 & F31 12 10
CB
F14 Salon lights From service bat. via S3 via F28 & F32 12 16
CB
F15 Fresh water pump From service bat. via S3 via F28 & F32 12 10
CB
F16 Engine blowers From service bat. via S3 via F28 & F32 12 16
CB
F17 Wiper, Sliding roof From service bat. via S3 via F28 & F32 12 32
CB
F18 Navigation, anchor lights From service bat. via S3 via F28 & F32 12 10
CB
F19 Autopilot From service bat. via S3 via F28 & F32 12 32
CB
F20 Defroster From service bat. via S3 via F28 & F32 12 25
CB
F21 Clutch actuator, cooling pump From service bat. via S3 via F28 & F32 12 16
CB
F23 Inverter/charger relay signal From service bat. via S3 via F28 & F32 12 10
ATO
F24 Diode splitter PORT From PORT diode splitter to PORT
engine battery
12 200
ANL
F25 Engine battery PORT Main PORT engine battery fuse 12 355
ANL
F26 Diode splitter STBD From STBD diode splitter to STBD
engine battery
12 200
ANL
F27 Engine battery STBD Main STBD engine battery fuse 12 355
ANL
F28 Service battery Main service battery fuse 12 200
ANL
F29 Diode splitter PORT From PORT diode splitter to service
battery
12 200
ANL
F30 Diode splitter STBD From STBD diode splitter to service
battery
12 200
ANL
F31 24h Consumers From service bat. via F28 12 35
ANL
