GREENLINE 40 - Page 83

Greenline 40 76
F32 Service consumers From service bat. via S3 via F28 12 100
ANL
F33 Battery charger OUT 1 (port) From battery charger to PORT diode
splitter
12 125
ANL
F34 Battery charger OUT 2 (stbd) From battery charger to STBD diode
splitter
12 125
ANL
F35 Bowthruster battery Main bowthruster battery fuse 12 500
ANL
F36 Diode splitter STBD From STBD diode splitter to
bowthruster battery
12 200
ANL
Q37 Anchor winch From bowthruster battery via S4 via
F35
12 80
CB
Anchor winch contactor
commands
From bowthruster battery via S4 via
F35
12 5
ATO
F38 Inverter/charger From LiPo battery via K7 48 160
ANL
F39 Solar panels From solar panels to LiPo battery via
relays K8 & K9
48 35
ANL
F40 Sternthruster battery Main sternthruster battery fuse 12 500
ANL
F41 Diode splitter PORT From PORT diode splitter to
sternthruster battery
12 200
ANL
F42 Anchor winch (stern) From sternthruster battery via S5 via
F40
12 100
CB
F43 LiPo battery 1 Main LiPo battery 1 fuse 48 300
ANL
F44 LiPo battery 1 Main LiPo battery 2 fuse 48 300
ANL
F45 HCU - PORT Main HCU – PORT fuse 48 300
ANL
F46 HCU - STBD Main HCU – STBD fuse 48 300
ANL
QS
main
Shore power supply - RCCB From shore power cable 230 16/2/0.03
CB
QS AC Air condition shore power
supply - RCCB
From air condition shore power cable 230 16/2/0.03
CB
QS1 General RCCB From QS main (via Inverter/charger –
hybrid only)
230 32/2/0.03
CB
FS2 Water heater From QS main 230 16
CB
FS3 12V Charger From QS1 230 10
CB
FS4 Sockets, TV From QS1 230 16
CB
FS5 Hob, Oven From QS1 230 16
CB
FS6 Fridge, Washing machine From QS1 230 16
CB
FS7 Air condition From AC selector switch (from QS AC 230 16
CB
