GREENLINE 40 - Page 84

Greenline 40 77
or from QS1 (depends on selection))
K1 Engine blowers From F16 (control from engine keys
& hybrid switch (D) via D1 & D2)
12 40
Relay
K2 Defroster From F20 (control from defroster
carling switch)
12 40
Relay
K3 Hybrid pump & HCU relay
signal (port)
From F21 (control from port engine
key switch)
12 30
Relay
K4 Hybrid pump & HCU relay
signal (stbd)
From F21 (control from stbd engine
key switch)
12 30
Relay
K5 HCU – STBD From LiPo battery 48 500
Relay
K6 HCU – PORT From LiPo battery 48 500
Relay
K7 Inverter/charger From LiPo battery 48 500
Relay
K8 Solar panels From F39 to LiPo battery (control
from BMS solar output)
24 40
Relay
K9 Solar panels From F39 to LiPo battery (control
from BMS solar output)
24 40
Relay
D3 Hybrid pump From F21 via K3 12 20
Diode
D4 Hybrid pump From F21 via K4 12 20
Diode
