Automatic Greasing System OnePlus
Description components
11
Date of issue: October 2011
EG1605R01
2.4 Selector switches
The integrated control and monitoring unit features two selector switches for
controlling (see Figure 2.3):
• the interval in between the cycle starts and
• the amount of grease per greasing cycle
Figure 2.3 Selector switches
2.4.1 Setting possibilities selector switches
ATTENTION
In indivudal cases the times and amounts behind the selector switches
settings can be customized and differ from the above displayed factory
settings.
Time interval Grease amount
1 5 minutes 1 cc per cycle
2 10 minutes 2 cc per cycle
3 15 minutes 3 cc per cycle
4 30 minutes 4 cc per cycle
5 45 minutes 5 cc per cycle
6 60 minutes 6 cc per cycle
7 90 minutes 7 cc per cycle
8 120 minutes 8 cc per cycle
9 180 minutes 9 cc per cycle
0 240 minutes 10 cc per cycle
55
TIME AMOUNT
selector switch
time interval
selector switch
grease amount
