Automatic Greasing System OnePlus
Installation
33
Date of issue: October 2011
EG1605R01
4.8 Electrical wiring
4.8.1 General
Detailed wiring diagrams are available in the installation manual of the specific ve-
hicles or machines.
ATTENTION:
To prevent damage to the electrical system of the vehicle or machine, the
correct fuse(s) must be installed in power supply and control circuit.
On VLG vehicles special demands are placed on:
• the components (e.g. pump, wiring and switches).
• the location of the components on the vehicle.
• the manner in which the greasing system is to be connected to the vehicle’s
electrical system.
Always verify whether the system you are installing and the methods you plan to
use meet those demands.
• Install the wiring only after the main components of the greasing system have
been mounted (e.g. pump unit, indicator lamp, monitoring switches on the
distribution blocks).
• Try, as far as possible, to route the electrical wiring along the grease lines, and
fix the wiring in place together with the grease lines.
4.8.2 Fuse ratings
4.8.3 Pin-layout of the connector on the pump unit
Voltage Supply circuit fuse Control circuit fuse
12 Vdc 15 A 3 A
24 Vdc 7,5 A 3 A
Pin number
connector
Description connection
1 Supply voltage (+15)
2 Ground (-31)
3 Additional control input (can be a voltage or a ground)
4 Indicator lamp (-)
5 Indicator lamp (+)
6 K-line (communication with the UniGINA)
7 Distribution block monitoring switch
8 Distribution block monitoring switch
