Groeneveld OnePlus - Technical Data and Specifications; OnePlus Pump Unit Specifications

Automatic Greasing System OnePlus
Technical data
41
Date of issue: October 2011
EG1605R01
6 Technical data
6.1 OnePlus pump unit
* Other grease reservoirs are available on request.
** Depending on the ambient temperature (consult your grease supplier).
Figure 6.1 Dimensions of the OnePlus pump unit with a 2 litre reservoir.
Maximum operating pressure : 275bar
Operating temperature : -20 ... +60 °C
Supply voltage : either 12 or 24 Vdc
Rating pump motor (nominal at 20 °C) : 36 W
Rest current : 40 mA
Capacity grease reservoir (standard) : 2 litres *
Minimum-level switch : none
Number of output ports : 1
Pump material
: hard anodised aluminium - nylon
reinforced
Pump delivery : 0,1 cc per stroke
Protection class : IP67 (for lower part of pump unit)
Grease types : NLGI 2 **
338
250 162
270
100 187
