Installation30
Date of issue: October 2011
Automatic Greasing System OnePlus
EG1605R01
Press couplings (applied with a hydraulic press) for high-pressure
grease line DN6 (00817):
a. Check that the press is fitted with the correct type of press blocks, and the
set press diameter. The correct press diameter for this type of grease line is
14,6 mm.
b. Slide the sleeve over the end of the grease line, until it covers the line com-
pletely.
c. Slide, use some oil if necessary, the pillar or the required coupling pin into
the end of the grease line until the pillar is completely in the grease line.
d. Pull the sleeve back slamply until it touches the outside edge of the cou-
pling pin. While doing this, ensure that the pillar remains in place and is
not pressed out of the grease line.
e. Place the assembly into the press and press the sleeve to the required
diameter (14,6 mm).
f. Check the resulting diameter by measuring it (between ridges that may
have formed).
g. Mount the coupling at the other end of the grease line in a similar way.
3. Remove any burrs and other remnants produced by cutting the line, and
clean the grease line by blowing it through. Check that the line is free of
obstructions and check it for internal damage behind the couplings (the inner
lining may have been upset).
4. Fill the line with grease. Either use a pneumatic or hand-operated grease gun.
5. Install the grease line and fix it in place with tie-wraps or clamps. Do not yet
connect the primary grease line(s) to the output port(s) of the pump unit, if
you want to use the pneumatic or hand-operated grease gun to de-aerate the
system.
ATTENTION:
Always use steel cutting rings when using metal grease lines and couplings.
