11.5.6 Setting of individual operating mode (2.1.4.1 to 2.1.4.6)
Fig. 27 Setting of individual operating mode
Description
This display is shown for the individual pumps and makes it
possible to set an operating mode.
Setting range
It is possible to select Auto or Manual as well as the operating
mode of the pump for manual operation - Max., Normal, Min. or
Stop. For mains-operated pumps only Normal or Stop can be
selected.
Setting via control panel
1. Mark the Operation menu with .
2. Mark Individual pump control with or , and press
.
3. Select the pump with or , and press .
4. Mark Auto or Manual with or , and press .
5. Manual: Select the operating mode with or , and
press .
6. Normal: Mark Setpoint with or .
Set the speed of the variable-speed pump with or ,
and press .
Factory setting
Auto.
TM03 8954 4807
