Env.Type:
PF:
CL:
IP:
INPUT
U in:
f in: Hz
OUTPUT
n: rpm
PDS Eff
XXX
V
:
%
Variant
PB:
FM:
HMI:
CIM:
Made in Hungary
I1/1: A
P2: kW
~ V
Tamb: C
DE:
NDE:
Wgt: kg
Type:
P.N.: -V
P.C.:
OUTPUT
rpm
XXXV
:
%
Variant
PB:
FM:
HMI:
CIM:
kW
TM082851
Model K
Functional module variants:
• FM110
• FM310
• FM311
1)
1)
Without Bluetooth (BLE).
2.3.4 Identification of the operating panel
You can identify the operating panel in one of the
following ways:
Grundfos GO
You can identify the operating panel in the Fitted
modules menu under Status.
Motor display
For motors fitted with the HMI 300 or 301 operating
panel, you can identify the operating panel in the
Fitted modules menu under Status.
Motor nameplate
You can identify the operating panel by means of the
data on the motor nameplate.
Env.Type:
PF:
CL:
IP:
INPUT
U in:
f in: Hz
OUTPUT
n: rpm
PDS Eff
XXXV
:
%
Variant
PB:
FM:
HMI:
CIM:
Made in Hungary
I1/1: A
P2: kW
~ V
Tamb: C
DE:
NDE:
Wgt: kg
Type:
P.N.: - V
P.C.:
OUTPUT
rpm
XXX
V
:
%
Variant
PB:
FM:
HMI:
CIM:
kW
TM082852
Model K
Operating panel variants
• HMI 100
• HMI 101
2)
• HMI 200
• HMI 201
2)
• HMI 300
• HMI 301
2)
2)
For motors without a radio module.
2.4
Radio module
CAUTION
Radiation
Minor or moderate personal injury
‐ Locate the product at a minimum
distance of 20 cm from any body parts.
Human tissue may be heated by RF
energy.
Installers and end users must be provided
with these installation and operating
instructions and operating conditions for
satisfying RF exposure compliance.
The product incorporates a class 1 radio module for
remote control. You can use the module anywhere in
the EU without restrictions.
For installation in the USA and Canada, see the
appendix.
Via the built-in radio module, the product can
communicate with other MGE motors.
The product contains a class 1 radio.
Grundfos will support the product with
security updates for at least 2 years from
production of the unit.
2.5 Bluetooth
The product incorporates a Bluetooth (BLE) module
for remote control. You can use the module anywhere
in the EU without restrictions.
For installation in the USA and Canada, see the
appendix.
Via the built-in Bluetooth module, the product can
communicate with Grundfos GO.
The product contains a Bluetooth (BLE)
module. Grundfos will support the product
with security updates for at least 2 years
from production of the unit.
Bluetooth information
Frequency of operation
2400 - 2483.5 MHz
Modulation type GFSK
Data rate 2 Mbps
Transmit power
5 dBm EIRP with internal
antenna
GLoWpan information
Frequency of operation
2405-2480 MHz
Modulation type GP O-QPSK
Data rate 1 Mbps
Transmit power
5 dBm EIRP with internal
antenna
8
English (GB)
To Next Page
Loading...
