User Manual 9065/9065plus
MAN10772-00 124
Optional Configuration
FRONT2 PUSH TRACTOR (4 pin)
Fanfold Width: 76 to 432 mm (3 to 17 inches)
Copies: 1 original + 7 copies
Thickness Max. 0,635 mm (0.025 inches)
Physical and Electrical Characteristics
Interfaces with Automatic interface switching
Parallel Centronics Compatible Bi-directional (IEEE-1284) nibble and byte
modes - 36 pin Amphenol connector, 7/8 data bits
Receive Buffer: max. 128 Kbytes
Serial RS-232/C - dB 9 connector, Baud Rate: 300 to 115200 bps, 7/8
data bits, DTR & XonXoff flow, Receive Buffer: max. 128 Kbytes
USB Type B USB 2.0 Compatible Bi-directional - 4 pin connector,
12Mbit/s
LAN 10BASE-T – 100BASE-TX – RJ45 8 pin connector
Reliability
MTBF Mean Time between failure: 20,000 hours at 25% DC
MTTR Mean Time To Repair: 30 minutes
Workload 50000 pages/month (ECMA 132 - 4 hours for 22 days)
Printer Life 5 years
Print Head Life 800 MChrs
Power Supply
UNIVERSAL From 90 to 244 VAC
Power Output Max. 154 W
Power Consumption Standby: 22W - Printing: 116 W
Noise Level
< 54 dBA
Environment Conditions
Temperature Relative Humidity
Storage Conditions -40° to 50° C 10% to 90% RH (not condensing)
Operating Conditions 10° to 38° C 10% to 90% RH (not condensing)
Paper Conditions 16° to 24° C 40% to 60% RH (not condensing)
Physical dimensions
Height 315 mm (12,21 inches)
Width 670 mm (26,18 inches)
Depth 390 mm (15,35 inches)
Height 315 mm (12,21 inches)
Basic Printer
9065plus
PRTN965P
Consumables
Black ribbon cartridge (15 million chs.) PRKN407
Options
Additional 4 pin Front2 Push Tractor PRFN2TR4
Three Level Floor Pedestal PRFN-PD1
Controller Parallel-Serial-USB (only 9065) PRAN965
Controller Parallel-LAN (only 9065) PRAN965N (not more available)
Standards
IEC 60950-1:2001, EN 60950-1:2001, EN55022, CISPR22, EN55024, EN61000-3-2 , EN61000-3-3, EN27779
