User Manual 9065/9065plus
MAN10772-00 92
How to Select the Paper Path
The paper can be loaded into the printer using different paper paths. The messages indicating the paper paths
are shown depending upon the printer model and if the corresponding loading device is installed on the printer.
Proceed as follows:
1. Press the
ON
LINE
key to put the printer offline (
ON
LINE
indicator unlit).
2. Press the
PATH
key, according to the installed devices the following messages are displayed:
PATH
FRONT
1
For the paper path using the Front1 push tractor.
PATH
FRONT
2
For the paper path using the Front2 push tractor option.
To load fanfold paper go to “Loading Paper Using the Front1 Push Tractor”, “Loading Paper Using the
Front2 Push Tractor (option)”. When a new paper path is selected, the paper loaded in the printer is automatically
parked.
How to Use the Tear-Off Function
This function is used to match the paper perforation with the tear-off bar. For this function the following values must
be set:
Selection of the Paper Size
1. Press the
PROGRAM
key when the printer is disabled or enabled without printing to enter the
Program Setup.
2. Press the ↓ key and the following message appears:
USER MACRO
3. Press the
→
key to select the macro for which you want to set the paper size (MACRO#1, MACRO#2,
MACRO#3 or MACRO#4).
4. Once the desired macro is displayed press the ↓ key until the following parameter is displayed:
LENGTH xx
5. Press the
→
or
←
key until the desired page size is displayed.
6. Press again the
PROGRAM
key to exit the setup and set the new value.
