User Manual 9065/9065plus
MAN10772-00 93
Adjusting the Tear-Off Position
To check the Tear-Off Position proceed as follows:
1. Check if the paper perforation matches the tear-off bar on the printer.
2. To move manually the paper to the Tear-Off position, press the
TEAR
key when the printer is enabled without
printing (TEAR NORMAL function selected YES in the Program Setup).
You can leave the manual tear off function by pressing again the
TEAR
key
If it does not:
1. Turn the printer off and press the
PROGRAM
key and hold it pressed while powering on the printer until the
RELEASE
KEYS
message is displayed to enter the Power-On Configuration.
2. Press the ↓ key until the following message appears:
FUNCTIONS
3. Press the → key to enter and then press the ↓ until the following message is displayed:
TEAR ADJUST xxx
4. Press the
→
or
←
key to scroll the values of this function.
Values below 0 move the tear-off position downwards, values above 0 move the paper
upwards. The values can be set between +30 and -390 at 1/180 inches (from +1/6 to -13/6
inches).
5. When the desired value is displayed, press the
PROGRAM
key.
6. Press the
PROGRAM
key to save and exit from the setup.
Selection of the Tear-Off Mode
It is now possible to select the Tear-Off Mode.
1. Press the
PROGRAM
key when the printer is disabled or enabled without printing to enter the
Program Setup.
2. Press the ↓ key. The following message is displayed:
USER MACRO
3. Press the
→
key to select the macro for which you want to set the tear-off mode (MACRO#1,
MACRO#2, MACRO#3 or MACRO#4).
4. Press the ↓ key, until the following message is displayed:
TEAR NORMAL
Pressing the
→
or
←
key it is now possible to decide how to execute the tear off function:
