User Manual 9065/9065plus
MAN10772-00 54
LAN Interface
The following LAN interface parameters will display only if the Ethernet 10/100 Mbit
interface is present
This setup defines the use of the LAN interface and is structured according to the interface specific parameters.
Setting the LAN Interface Parameters
IP Assignment
PARALL INTERFACE LAN INTERFACE
↑
↑
LAN INTERFACE
→
IP ASSIGN FIXED
→
or
←
↓
IP ASSIGN DHCP
→
or
←
FUNCTIONS
↓
INIT IP ADDRESS 127.000.000.000
IP ASSIGN FIXED
Assigns the static or fixed IP address.
IP ASSIGN DHCP
Assigns the dynamic IP address (DHCP protocol).
