User Manual 9065/9065plus

MAN10772-00 75
Pitch Selection
FONT Draft
↑
PITCH 5 CPI
→ or ←
PITCH 6 CPI
→ or ←
PITCH 7.5 CPI
→ or ←
PITCH 8.5 CPI
→ or ←
PITCH 10 CPI
→ or ←
PITCH 12 CPI
→ or ←
PITCH 15 CPI
→ or ←
PITCH 17.1 CPI
→ or ←
PITCH 20 CPI
→ or ←
PITCH 24 CPI
→ or ←
PITCH PROP
→ or ←
↓
15&24CPI NORMAL
These items set the horizontal spacing in characters per inch. The PITCH PROP item sets proportional character
spacing.
Micro Dot Print Mode
PITCH 10 CPI
↑
15&24CPI NORMAL
→ or ←
15&24CPI MICRO
→ or ←
↓
PITCH LOCK NO
15&24CPI MICRO
The print matrix uses 8 x 8 dots only if the horizontal spacing is 15 or 24 cpi (micro mode).
15&24CPI NORMAL
The print matrix uses 12 x12 dots (normal mode).
Pitch Lock
15&24CPI NORMAL
↑
PITCH LOCK NO
→ or ←
PITCH LOCK YES
→ or ←
↓
LEFT MARGIN 0
PITCH LOCK NO
Setting this item, the pitch can be changed by software or operator panel.
PITCH LOCK YES
Setting this item, the pitch can be changed ONLY by operator panel.
