Model 675 User Instructions 21
Style 1
The top display will show the weight or quantity in larger font while the second display
will show the part number in medium font. Press the [SELECT] key from the
Application Menu screen to toggle through the different parameter choices.
Style 2
This style incorporates the classic GSE 2x5 display and a second display, which will
show three other parameters. Press the [SELECT] key from the Application Menu
screen to toggle through the different parameter choices.
Style 3
This style incorporates the classic GSE 2x5 display along with three smaller displays
which will show four other parameters. Press the [SELECT] key from the Application
Menu screen to toggle through the different parameter choices.
Large display Medium display
Gross Part #
Net Part #
Tare Part #
APW (average piece weight) Part #
% Accuracy Part #
Last Sample Part #
Quantity Total Part #
# Accumulations Part #
Quantity Part #
Large Display Small Display Small Display Small display
Quantity Part# APW Description
Gross Part# APW Description
Net Part# APW Description
Tare Part# APW Description
Large Display Small Display Small Display Small display
Quantity Gross Net Tare
Quantity Part# Piece Weight Tare
Quantity Net Tare Gross Total
Gross Part# % Accuracy Piece Weight
Quantity Part# % Accuracy APW x 100
Quantity Piece Weight % Accuracy Tare
