GSE 675 - Hardware Error Codes

40 Model 675 User Instructions
5.2 Hardware Errors
Message Description
CoDE17
A/D
BAD!
The processor has detected a problem with the A/D chip. Several situations could cause
this error message to be displayed. The most severe situation would be a damaged or
defective A/D. In this case it will have to be replaced.
CoDE18
BufSz
Max!
The accumulative total buffer size for both the TX and RX buffers of all COMM ports
exceeds the reserved storage capacity 8192 bytes.
CoDE19
"Data
&Stop
Certain combinations of protocol are not available.
CoDE20
Defit
A/D
The A/D calibration data is corrupt
CoDE21
Write
NVErr
Error reading data from the FRAM.
CoDE22
Read
NVErr
Error writing data to the FRAM.
CoDE23
Check
NVPar
Supplementary error message for above errors.
CoDE24
NVPar
Full!
The setup being attempted requires more FRAM than is currently installed.
CoDE25
Defit
Setup
Upon power-up the indicator has not found the proper codes. Therefore, all parameters
have been reset to factory default values.
CoDE26
Bad
Setup
The stored data has a checksum error. Check all parameters or re-load setup.
CoDE27
RE-
BOOT!
The indicator cannot use the FRAM for data storage and is attempting to power-up again
to cure the problem.
CoDE29
PIN
error
The FRAM is corrupted in the PIN section.
