Chapter 3 Structure and Configuration
3.1 Appearance and Internal Structure
GST200 FACP is wall-mounted. Its appearance and internal structure are shown in Fig.
3-1 and 3-2.
1
7
6
5
4
3
2
Fig. 3-1
1 Clock 2 LCD 3 Printer panel 4 Optional units 5 LED 6 Keypad
7 Zone indication and manual intervention panel (ZCP)
Fig. 3-2
1 Display control (main board, switch board, LCD) 2 Zone indication and manual
intervention panel (ZCP) 3 Printer 4 Optional units (FCP-fireman’s control panel)
5 Speaker 6 Power supply 7 Loop interface board 8 Transformer 9 PSU filter
