GST200 Intelligent Fire Alarm Control Panel
Installation and Operation Manual
The Intelligent Solution
Page 32
002 of 002 Disable 12:01 // There are devices from 2 zones that are disabled， and
this is the second zone.
Zone: 006－Z-006 // Zone number and description message of the disabled
zone.
016/030 //There are 16 disabled devices in all 30 devices of the current
zone.
Zone Part Disabled // The zone is partially disabled
6.2.2.8 Browsing action messages
You can view action messages by pressing VIEW PLANT when the screen is displaying
non-action messages. The screen is shown in Fig. 6-15.
001 of 004 ACTION 12:15
Zone:001-004Sounder
Office1
Fig. 6-15
001 of 004 ACTION 12:15 // There are 4 action messages in the system and this is
the first, time 12:15.
Zone:001-004Sounder //The zone number, device address and device of the
device in action.
Office1 //Description message of the device in action.
6.2.3 Silencing the panel
Pressing MUTE can stop the sound of speaker; pressing MUTE again, the FACP is still
in mute state. It will sound by priority when new event appears. If the conditions for
silencing the system is met (fire alarm silence delay settings and correct operation
password level), the system can also be silenced.
6.3 Instructions for Operator (Operator Password Required)
6.3.1 Resetting the system
Pressing RESET can turn off all the control modules, local outputs and reset all the
detectors, but will leave the disabled devices as they are. The LCD displays “RESET IN
SYSTEM”. LEDs will be turned off (Except for “POWER HEALTHY”, “DELAY MODE”,
“EXTINGUISHING SYSTEM PERMIT” LEDs). “RESET” information will be written into
running log. If there is still fire alarm, fault and action not acknowledged after pressing
the RESET key, the FACP will remain relative sound indications. If all messages have
been acknowledged by pressing RESET key, the system returns to normal display state.
