GST200 Intelligent Fire Alarm Control Panel
Installation and Operation Manual
The Intelligent Solution
Page 45
Chapter 8 Maintenance
The FACP shall only be repaired by specially trained GST technical service personnel.
Please disconnect the power before repair!
8.1 Replacing the Battery
Type of battery: Sealed lead-acid battery
Recommended period for replacing the battery: 5 years (25℃)
Recommended manufacturer and model: Yuasa/NP17-12I
Disposal of used batteries: Please properly dispose the used batteries according to
your local rules and regulations.
NOTE: RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT
TYPE.
8.2 Replacing the Fuses
Table 8-1
Location Mark Rated Value
Power filter F7.820.323 F1 2A Delay
Power board F7.820. 829 F1, F2 5A
Loop interface board F7.820. 828 F1, F2, F3 2A
8.3 Troubleshooter
