GW Instek ASR-2000 Series Programming Manual

REMOTE CONTROL
109
Display Command
:DISPlay[:WINDow]:DESign:MODE ............... 109
:DISPlay[:WINDow]:MEASure:SOURce<1|2|3>
............................................................................... 109
:DISPlay[:WINDow]:DESign:MODE
Set
Description
Sets two display mode.
Syntax
:DISPlay[:WINDow]:DESign:MODE{NORMal|SIMPle}
Parameter
MORMal
Configure setup and Measurement.
SIMPle
All measurement times.
Example
:DISP:DES:MODE NORM
Sets standard normal display.
:DISPlay[:WINDow]:MEASure:SOURce<1|2|
3>
Set
Description
Sets standard normal display to measurement
items 1 – 3.
Syntax
:DISPlay[:WINDow]:MEASure:SOURce<1|3>
{ VRMS|VAVG|VMAX|VMIN|IRMS|IAVG|IMAX|IMIN|IP
KH|RPOWer|SPOWer|QPOWer|FREQuency|PFACtor|C
FACtor|THDV|THDI}
Parameter
Item 1
VRMS , VAVG , VMAX , VMIN ,
RPOWer , SPOWer
*1
, QPOWer
*1
, THDV
*2
Item 2
IRMS , IAVG , IMAX , IMIN , IPKH ,
PFACtor
*1
, CFACtor
*1
, THDI
*2
Item 3
RPOWer , SPOWer
*1
, QPOWer
*1
, IPKH ,
PFACtor
*1
, CFACtor
*1
, FREQuency
*3
Note
*1:
Not available for DC-INT
*2:
Available for AC-INT only
*3:
Available for AC+DC-Sync & AC-Sync
only
