GW Instek ASR-2000 Series - GPIB Remote Interface (Optional 1)

REMOTE CONTROL
31
8. The terminal display will return the following:
GWINSTEK, ASR-2XXX, GXXXXXXXX,
XX.XX.XX.XXXX-X
(manufacturer, model, serial number, software
version)
9. If Realterm fails to connect to the ASR-2000,
please check all the cables and settings and try
again.
GPIB Remote Interface (Optional 1)
GPIB
Configuration
1. Connect a GPIB cable from
the PC to the GPIB port on
the rear panel.
2. Press the Menu key. The Menu
setting will appear on the display.
3. Use the scroll wheel to go to item 6, GPIB and
press Enter.
4. Set the GPIB address.
GPIB Address
0 ~ 30 (10 by default)
GPIB Configuration
Note
Only one GPIB address can be used at a time.
