ASR-2000 Programming Manual
106
[:SOURce]:SIMulation:TRANsition<1|2>
:TIME
Set
Query
Description
Sets or queries the Time parameter of the transition
step for the Simulation mode.
Syntax
[:SOURce]:SIMulation:TRANsition<1|2>:TIME
{<NR2>|MINimum|MAXimum}
Query Syntax
[:SOURce]:SIMulation:TRANsition<1|2>:TIME?
[MINimum|MAXimum]
Parameter/Return
parameter
<NR2>
Time of the step in seconds
MINimum
0
MAXimum
999.9999s
Example
:SIM:TRAN1:TIME 1
Sets the step time to 1 second.
[:SOURce]:SIMulation:TRANsition<1|2>:CO
DE
Set
Query
Description
Sets the external trigger output for the transition
step parameter. This option is only applicable
when in the Simulation mode.
Syntax
[:SOURce]:SIMulation:TRANsition<1|2>:CODE
{<NR1>|MINimum|MAXimum}
Query Syntax
[:SOURce]:SIMulation:TRANsition<1|2>:CODE?
[MINimum|MAXimum]
Parameter/Return
parameter
<NR1>
0=LL, 1=LH, 2=HL, 3=HH
MINimum
0 (LL)
MAXimum
3 (HH)
Example
SIM:TRAN1:CODE 1
