GW Instek ASR-2000 Series - Measure[:Scalar]:Current:average; Measure[:Scalar]:Current:harmonic:ratio; Measure[:Scalar]:Current:harmonic[:Rms]; Measure[:Scalar]:Current[:Rms]

REMOTE CONTROL
59
Return
<NR2>
Returns the peak hold value in amps.
:MEASure[:SCALar]:CURRent[:RMS]
Query
Description
Returns the output current (Irms).
Query syntax
:MEASure[:SCALar]:CURRent[:RMS]?
Return
<NR2>
Returns the Irms value.
:MEASure[:SCALar]:CURRent:AVERage
Query
Description
Returns the current average value (Iavg).
Query syntax
:MEASure[:SCALar]:CURRent:AVERage?
Return
<NR2>
Returns the current average value in amps.
:MEASure[:SCALar]:CURRent:HARMonic[:RMS]
Query
Description
Returns 41 values covering Total and order 1 to 40
current (Irms) in harmonic. (Only AC-INT and 50
/60 Hz Active)
Query syntax
:MEASure[:SCALar]:CURRent:HARMonic[:RMS]?
Return
<NR2>,<NR2
>,<NR2>,
<NR2>…, etc.
Returns the entire 41 values
containing Total and order 1 to 40
current (Irms) in harmonic.
:MEASure[:SCALar]:CURRent:HARMonic:RATio
Query
Description
Returns 41 values covering Total and order 1 to 40
current (Ratio) in harmonic. (Only AC-INT and 50
/60 Hz Active)
Query syntax
:MEASure[:SCALar]:CURRent:HARMonic:RATio?
Return
<NR2>,<NR2
>,<NR2>,
<NR2>…, etc.
Returns the entire 41 values
containing Total and order 1 to 40
current (Ratio) in harmonic.
