APPENDIX
121
DC-INT Mode
ASR-2050
ASR-2050R
ASR-2100
ASR-2100R
Range
100V
DCV
0.0 Vdc
I
5.25 A
10.50 A
V Limit
+/- 250.0 Vpp
IPK Limit
+/- 21.00 A
+/- 42.00 A
AC+DC-EXT Mode
ASR-2050
ASR-2050R
ASR-2100
ASR-2100R
Range
100V
GAIN
100.0
IRMS
5.25 A
10.50 A
IPK Limit
+/- 21.00 A
+/- 42.00 A
AC-EXT Mode
ASR-2050
ASR-2050R
ASR-2100
ASR-2100R
Range
100V
GAIN
100.0
IRMS
5.25 A
10.50 A
IPK Limit
+/- 21.00 A
+/- 42.00 A
AC+DC-ADD Mode
ASR-2050
ASR-2050R
ASR-2100
ASR-2100R
Range
100V
Wave Shape
SIN
ACV
0.0 Vrms
DCV
+0.0 Vdc
GAIN
100.0
FREQ
50.00 Hz
IRMS
5.25 A
10.50 A
V Limit
+/- 250.0 Vpp
F Limit Lo
1.0 Hz
F Limit Hi
999.9 Hz
IPK Limit
+/- 21.00 A
+/- 42.00 A
ON Phs
0.0
o
OFF Phs
0.0
o
