GW Instek ASR-2000 Series Programming Manual

ASR-2000 Programming Manual
56
Description
Sets the arbitrary wave.
Syntax
:DATA|TRACe:WAVe[:DATA] {<NR1>|<Binary Data>}
Parameter
<NR1>
1 – 16 (ARB 1 – 16)
Binary Data includes the #48192<DAB>...<DAB>
#
Indicates the block data is sent.
4
Indicates the number of subsequent numbers.
8192
Indicates the number of subsequent byte data.
<DAB>..
.<DAB>
Indicates 16-bit with 4096 words waveform
data. Plus, the data format of wave is the big
endian in the form of two’s complement.
Example
TRAC:WAV 1, #48192<DAB>...<DAB>
