GW Instek ASR-2000 Series User Manual

ASR-2000 Series User Manual
16
D
Test key/Output waveform key
E
Enter key
F
Preset key/Local mode key
G
Cancel key/ALM CLR key
H
Output key
I
Scroll wheel
J
Arrow keys
K
Air inlet
L
Hardcopy key
M
Output socket (ASR-2100/2050 only)
Item
Description
Power Switch
Turn on the mains power
USB A Port
The USB port is used for data transfers
and upgrading software. Also, it is
available for screenshot hardcopy in
association with the Hardcopy key.
Note
It supports FAT32 format with maximum 32G storage
only.
LCD Screen
Displays the setting and measured
values or menu system
Display Mode
Select Key
Selects between standard, simple and
harmonic analysis mode
