GW Instek ASR-2000 Series User Manual

ASR-2000 Series User Manual
206
Specifications
The specifications apply when the ASR-2000 is powered on for at
least 30 minutes.
Electrical specifications
Model
ASR-2050
ASR-2050R
ASR-2100
ASR-2100R
Input ratings (AC rms)
Nominal input voltage
100 Vac to 240 Vac
Input voltage range
90 Vac to 264 Vac
Phase
Single phase, Two-wire
Nominal input Frequency
50 Hz to 60 Hz
Input frequency range
47 Hz to 63 Hz
Max. power consumption
800 VA or less
1500 VA or less
Power factor
*1
100Vac
0.95 (typ.)
200Vac
0.90 (typ.)
Max. input current
100Vac
8 A
15 A
200Vac
4 A
7.5 A
*1
For an output voltage of 100 V/200 V (100V / 200V range), maximum
current, and a load power factor of 1.
