Using the Rack Mount Kit
Background
The ASR-2000 and ASR-2000R have the following
optional Rack Mount kits, respectively.
Unit Model
Rack Mount kit part number
ASR-2000
ASR-2000R
GRA-439-E
ASR-2000
ASR-2000R
GRA-439-J
The GRA-439-E is designed to fit into an EIA rack
of 3U-height, while the GRA-439-J is designed to fit
into a JIS rack of 3U-height. Please see your
distributor for further rack mount details.
GRA-439-E Series
GRA-439-E Rack
Mount Diagram
(ASR-2000)
GRA-439-E Rack
Mount Diagram
(ASR-2000R)
GRA-439-E Rack
Mount Diagram
(Dual ASR-2000Rs)
