OPERATION

GRA-439-J Series

GRA-439-J Rack

Mount Diagram

(ASR-2000)

GRA-439-J Rack

Mount Diagram

(ASR-2000R)

GRA-439-J Rack

Mount Diagram

(Dual ASR-2000Rs)

CAUTION

Ensure adequate ventilation is provided when using

the rack mount. Ensure that a gap is given for air

intakes. Failure to do so may cause the instrument to

overheat.
