GW Instek ASR-2000 Series User Manual

OPERATION
81
Setting the Peak Current Limit
Background
Setting the peak current limit sets a limit on the
current that can be sourced by the power supply.
Once the output current over the setting, the output
will set to off.
Note
When the peak current limit is tripped, an alarm will
sound. Press Shift + Cancel to clear the Ipk alarm.
Steps
1. Press Shift + Irms to access the IPK
Limit menu.
+
2. Use the scroll wheel to toggle between IPK+
(upper) and IPK- (lower) settings followed by
pressing Enter to get into parameter, respectively.
IPK+
IPK-
