Manage Arbitrary Waveform Settings
Arbitrary waveform settings can be easily saved to or from a USB
flash drive using the Save/Recall Files utility in the Menu system.
Files can also be deleted from local memory using the utility.
File Format
When files are saved to USB they are saved in the
following format:
ARBX.ARB, where X is the memory number
1 ~ 16 (ARB0 ~ ARB16). The files are saved to
USB:/gw.
When files are recalled from USB, files must be
recalled from the same memory number. For
example, the file ARB1. SEQ can only be recalled to
memory number ARB1. The files can only be
recalled from the USB:/gw directory.
Steps
1. Press the Menu key. The Menu
settings will appear on the display.
2. Use the scroll wheel to go to item 10, Save/Recall
Files and press Enter.
3. Go to the Type setting using the scroll wheel
and press Enter. Select ARB and press Enter to
confirm.
4. Go to the Action setting and choose the file
operation and then press Enter.
MEMUSB
Saves the selected ARB
memory from the local memory
to a USB flash drive.
MEMUSB
Loads the ARB memory from a
USB flash drive to the selected
local memory.
