COMMUNICATION INTERFACE
183
Exit
5. Press Exit[F4] to exit from the GPIB
settings.
GPIB Constraints
 Maximum 15 devices altogether, 20m cable length,
2m between each device
 Unique address assigned to each device
 At least 2/3 of the devices turned On
 No loop or parallel connection
Note
The optional 1 interface does Not include GPIB data
cable. Please purchase the additional GTL-258 which
will meet your need for GPIB connection.
GPIB Function Check
Functionality
Check
Please use the National Instruments Measurement
& Automation Controller software to confirm
GPIB/LAN functionality.
See the National Instrument website,
http://www.ni.com for details.
Note
 For further details, please see the programming
manual, available on the GW Instek web site @
www.gwinstek.com
 Operating System: Windows XP, 7, 8, 10
Operation
1. Start the NI Measurement and
Automation Explorer (MAX)
program. Using Windows, press:
