GW Instek ASR-2000 Series - Sequence Settings

TEST MODE FUNCTION
147
Note
The Remote Sense will be forcibly set OFF and Slew
Rate Mode is set to time after entering the SEQ Mode.
It will automatically return to the previous setting after
exiting from the SEQ Mode.
Sequence Settings
Entering the
Sequence Menu
1. Press Test key.
Test
Alternatively, it is available to
navigate, with scroll wheel, to the
TEST SEQ… option followed by
pressing the Enter key to enter the
SEQUENCE menu.
Note
It is available for AC+DC-INT, AC-INT and DC-INT
modes only.
2. Press Seq/Sim[F1] key to toggle to the
SEQUENCE Mode.
Sequence Mode
F1 soft-key
Note
It is available for AC+DC-INT mode only.
Steps
3. Use the scroll wheel to go to the Step setting
and press Enter.
4. Use the scroll wheel to select the step number. 0
is always the starting step for the sequence.
