GW Instek ASR-3000 Series User Manual

EXTERNAL CONTROL
119
Compiling Arbitrary Waveform Input
Background
In order to generate arbitrary waveforms, it is
requested to use a specifically control software
on external PC which transfers data, via USB
interface, to the arbitrary waveform memory
with ASR-3000. Go to GWInstek official website
to download the ARB waveform compiling
program.
Note
 Arbitrary waveforms cannot be changed when
output is on. To change arbitrary waveform, make
sure the output is off beforehand.
 It is not allowed to compile the arbitrary waveform
memory directly from ASR-3000. Only connecting
with a PC with control software via USB interface
can complete it.
Memory
 Arbitrary waveform memory count: 16
 Arbitrary waveform length: 4096 words
 Arbitrary waveform data: 16-bit binary (2’s
complement format)
 Valid range of waveform data: -32767 to 32767
When a value greater than 32767 is input,
waveform data will be clipped to 32767. Also,
when a value less than -32767 is input, the
waveform data will be clipped to -32767.
Output Arbitrary
Waveform on
ASR-3000
1. Press Shift + Test to access the
Wave menu.
+
Alternatively, it is available to use
scroll wheel followed by the Enter key
to enter the Wave menu.
