GW Instek ASR-3000 Series User Manual

OPERATION
37
Set Up
Power Up
Steps
1. Connect the AC power
cords to the AC input
terminals.
 Red  Line (L)
 Black  Neutral (N)
 Green  GND ( )
Line
Neutral
Ground
2. Install the power cord
cover followed by
fastening the two
screws to fix the
cover.
3. The AC power cords
are perfectly
connected with the
AC input terminals.
4. Press the POWER key. The splash screen will
appear momentarily before the continuous
mode screen appears with the settings loaded.
CAUTION
The power supply takes around 20 seconds to fully
turn on and shutdown.
Do not turn the power on and off quickly.
