GW Instek ASR-3000 Series User Manual

ASR-3000 Series User Manual
216
Specifications
The specifications apply when the ASR-3000 is powered on for at
least 30 minutes.
Electrical specifications
Model
ASR-3200
ASR-3300
ASR-3400
ASR-3400HF
Input ratings (AC rms)
Nominal input voltage
200 Vac to 240 Vac
Input voltage range
180 Vac to 264 Vac
Phase
Single phase, Two-wire
Nominal input Frequency
50 Hz to 60 Hz
Input frequency range
47 Hz to 63 Hz
Max. power consumption
2500 VA
or less
3750 VA
or less
5000 VA
or less
5000 VA
or less
Power factor
*1
200Vac
0.95 (typ.)
Max. input current
200Vac
15 A
22.5
30 A
30 A
*1
For an output voltage of 100 V/200 V (100V / 200V range), maximum
current, and a load power factor of 1.
Model
ASR-3200
ASR-3300
ASR-3400
ASR-3400HF
AC mode output ratings (AC rms)
Voltage
Setting
Range
*1
0.0 V to 200.0 V / 0.0 V to 400.0 V
Setting
Resolution
0.1 V
Accuracy
*2
±(1 % of set + 1 V / 2 V)
Output phase
Single phase, Two-wire
Maximum
current
*3
100 V
20 A
30 A
40 A
40 A
200 V
10 A
15 A
20 A
20 A
Maximum
peak current
*4
100 V
120 A
180 A
240 A
160 A
200 V
60 A
90 A
120 A
80 A
Load power factor
0 to 1 (leading phase or lagging phase)
Power capacity
2000 VA
3000 VA
4000 VA
4000 VA
