How to Use the Instrument
Background
The ASR-3000 AC power supplies generally use
the scroll wheel, Arrow keys, Numerical Keypad
and Enter keys to edit numerical values or to
select menu options.
Menu navigation is performed using the menu
keys and function keys on the front panel.
The following section will explain some of these
concepts in detail.
Selecting Menu
Items
1. Turn the scroll wheel to select
parameters in menus and lists. The
selected parameter will be
highlighted in orange. The scroll
wheel is also used to
increment/decrement setting
values.
2. Press the Enter key to edit the
parameter or to enter the selected
menu.
Example
The following is an example of the menu list
that appears when the Menu key is pressed.
Selected parameter
