GW Instek ASR-3000 Series User Manual

APPENDIX
217
Frequency
Setting range
AC Mode: 40.00 Hz to 999.9 Hz,
AC+DC Mode: 1.00 Hz to 999.9 Hz
AC Mode:
40.0 Hz to
5000 Hz,
AC+DC
Mode: 1 Hz
to 5000 Hz
Setting
resolution
0.01 Hz (1.00 to 99.99 Hz), 0.1 Hz
(100.0 to 999.9 Hz)
0.01 Hz
(1.00 to
99.99 Hz),
0.1 Hz
(100.0 to
999.9 Hz),
1 Hz (1000
to 5000 Hz)
Accuracy
0.02% of set (23 °C ± 5 °C)
Stability
*5
± 0.005%
Output on/off phase
0° to 359° variable (setting resolution 1°)
DC offset
*6
Within ± 20 mV (TYP)
*1
100 V / 200 V range
*2
For an output voltage of 20 V to 200 V / 40 V to 400 V, an output frequency of
45 Hz to 65 Hz, no load, and 23℃ ± 5℃
*3
For an output voltage of 1 V to 100 V / 2 V to 200 V. Limited by the power
capacity when the output voltage is 100 V to 200 V / 200 V to 400 V. If there
is the DC superimposition, the current of AC+DC mode satisfies the
maximum current. In the case of lower than 40 Hz, and the power rating
temperature, the maximum current will be decrease.
*4
With respect to the capacitor-input rectifying load. Limited by the maximum
current.
*5
For 45 Hz to 65 Hz, the rated output voltage, no load and the resistance load
for the maximum current, and the operating temperature.
*6
In the case of the AC mode and 23°C ± 5°C.
