GW Instek ASR-3000 Series User Manual

ASR-3000 Series User Manual
218
Model
ASR-3200
ASR-3300
ASR-3400
ASR-3400HF
Output rating for DC mode
Voltage
Setting Range
*1
-285 V to +285 V / -570 V to +570 V
Setting
Resolution
0.1 V
Accuracy
*2
±(1 % of set + 1 V / 2 V)
Maximum
current
*3
100 V
20 A
30 A
40 A
40 A
200 V
10 A
15 A
20 A
20 A
Maximum peak
current
*4
100 V
120 A
180 A
240 A
160 A
200 V
60 A
90 A
120 A
80 A
Power capacity
2000 W
3000 W
4000 W
4000 W
*1
100 V / 200 V range
*2
For an output voltage of -285 V to -28.5 V, +28.5 V to +285 V / -570 V to -57 V,
+57 V to +570 V, no load, and 23℃ ± 5℃
*3
For an output voltage of 1.4 V to 100 V / 2.8 V to 200 V. Limited by the power
capacity when the output voltage is 100 V to 250 V / 200 V to 500 V.
*4
Limited by the maximum current.
Model
ASR-3000
Output voltage stability
Line regulation
*1
±0.2% or less
Load regulation
*2
0.5% or less (0 to 100%, via output terminal)
Ripple noise
*3
1 Vrms / 2 Vrms (TYP)
*1
Power source input voltage is 200 V, 220 V, or 240 V, no load, rated output.
*2
For an output voltage of 100 V to 200 V / 200 V to 400 V, a load power factor
of 1, stepwise change from an output current of 0 A to maximum current (or
its reverse), using the output terminal on the rear panel.
*3
For 5 Hz to 1 MHz components in DC mode using the output terminal on the
rear panel.
Model
ASR-3200/3300/3400
ASR-3400HF
Output voltage waveform distortion ratio, Output voltage response time,
Efficiency
Total harmonic distortion (THD)
*1
<0.2 % @50/60 Hz
<0.3 % @<500 Hz
<0.5 % @500.1 Hz to
999.9 Hz
<0.2 % @50/60 Hz
<0.5 % @<500 Hz
<1 % @500.1 Hz to
2000 Hz
<2 % @2001 Hz to
5000 Hz
Output voltage response time
*2
100 µs (TYP)
