TEST MODE FUNCTION
153
AC/DC Voltage
Range
(ACV/DCV)
There are 2 voltage range settings: HI
200V & LO 100V, which result in
varied ranges of ACV and DCV
values, respectively.
Sets the frequency of the step. There
are 3 secondary frequency settings
that determine how the frequency is
output.
CT: Sets the frequency level of the
step immediately to Fset values.
KP: Sets the frequency level to “keep”
the frequency of the previous step.
SP: Linearly increases or decreases
the frequency from the end of the
previous step to the end of the
current step.
It is available for AC+DC-INT and AC-INT modes only.
Sets the outputting waveform of the
step. Up to 4 waves including sine,
square, triangle and arbitrary (1-16)
wave shapes are available.
It is available for AC+DC-INT and AC-INT modes only.
The Jump To setting determines
which step to jump to at the end of
the step. If Jump To is turned off, the
unit will follow the Term (Step
termination) setting for the step.
Determines the number of times to
loop the jump step.
