TEST MODE FUNCTION
173
3. Use the scroll wheel to go to the Step setting
and press Enter.
4. Use the scroll wheel to select one of the
simulate steps and press Enter.
Initial, Normal1, Trans1, Abnormal,
Trans2, Normal2
5. Go to the Time setting and set the duration of
the step.
0.0001 ~ 999.9999s (Normal1,
Normal2 and Abnormal)
0.0000 ~ 999.9999s (Trans1 and
Trans2)
Note: For Trans1 and Trans2, it
supports a value of 0, which will
skip the step.
6. In order to adjust ACV voltage range between
HI and LO, it is required to set up outside of the
SIMULATE menu. Refer to the page 67 for
details. The selected range will be shown on the
top bar.
