COMMUNICATION INTERFACE
187
4. Set the RS232C relative settings.
Baud rate
1200, 2400, 4800, 9600(default),
19200, 38400, 57600, 115200,
Data bits
7 bits, 8 bits(default)
Parity
None(default), Odd, Even
Stop bits
1 bit(default), 2 bits
RS232C Configuration
Exit
5. Press Exit[F4] to exit from the
RS232C settings.
Note
The standard accessory does Not include RS232
data cable. Please purchase the additional GTL-232
which will meet your need for RS232 connection.
